Designing a Wi-Fi Network

Designing a Wi-Fi Network


This is the first in a series of blogs on Wi-Fi operation, design, and troubleshooting.


Designing a Wi-Fi network is much easier if you have the right procedures and tools in place.


First you must collect data about the network:

  • What are the requirements of the network?
  • What is the goal of the new network?
  • What is it meant to achieve?
  • Are there any constraints you have to overcome?

Next you have to decide what wireless vendor is being used? One of the most important things to get is an accurate map (or plan) of the site and the various floors.

Now you need to validate the map(s), and confirm the accuracy. This usually involves a site visit. During your site visit, you may take measurement to test the walls, to see what they are made of, and check their dB loss for use in your model.


Your goal now, is to build a model, to simulate the environment, so you can see how signal propagates, and how the network will perform.


Next you test and validate the model, and plan AP positions.


To collect accurate data, and build an accurate model, the right tools are necessary. Ekahau provides a suite of tools that are invaluable for Wi-Fi network design:

  • Ekahau AI Pro
  • Ekahau Connect subscription
  • Ekahau Sidekick 2 (hardware)

When used together, these give you the ultimate toolset for designing Wi-Fi networks!


These packages include tools that run on local PC's, or mobile devices for easy data collection. They include cloud systems for advanced 3D simulation and modeling, along with advanced optimization and insights. They also include packet capture tools for analysis and troubleshooting.

You can easily use these tools to design a network model simulating the operation of your proposed network. They are so powerful, you can even capture data from your current network, build a model, and simulate how newer APs will operate.


One of the most amazing features is that you can capture a 2.4 and 5GHz Wi-Fi 5 or 6 network today, with your current AP equipment, and build a model, that can be leveraged to show how a brand new set of 6GHz Wi-Fi 7 APs will perform in a new network design! This is truly amazing!


Once you have designed your network model, you can order the equipment and create an installation plan.


Now you simply install the network, power it on, and then validate its operation again with the same tools, making fine tweaks and adjustments if necessary.


Then, as if by magic, “hey presto”, you have a wonderful Wi-Fi network that just works great!

Ekahau also provides award winning training that teaches you how to use these tools, and move from Wi-Fi novice to expert in easy-to-digest steps!


To learn about NC-Expert Consulting Services, to help you design and manage Wi-Fi networks, click here


To learn more about Ekahau, or get a Demo, click here: https://wifi.ekahau.com/demo-phil/


See you next time!

===


#General #Ekahau #NetworkDesign #WiFi


===
